LINEAR GUIDEWAYS AND ACTUATORS

HIWIN supplies many hi-tech industries with critical components for machine tools, medical equipment, vending machinery, material handling, and the automotive industry to name a few.

Anchor 2

LINEAR GUIDEWAYS - CARRIAGES AND RAILS

  • Ball Type:
    -Series HG, HGL, EG, QH-QE (silent version), WE (wide version).
    -Sizes 15-65
    -Square or Flange style bearing

  • Miniature Type:
    -Series; MG
    -Sizes 7-15
    -Standard and Wide version

  • P/N INFO

  • For information on caring for and maintaining your HIWIN products, see our page about HIWIN grease, dust-proof accessories, and self- lubrication kits HERE

SINGLE AXIS ROBOTS

KK SERIES

The KK single axis robot combines both ballscrew and guideway to achieve better performance on accuracy, stiffness, rapid installation, and space saving. The optimized U-rail not only guides the movement of the slider being driven by the ballscrew, but also can be used as a structural component when assembled into a multi-axis motion system.

  • Easy for system design, installation and maintenance

  • Compact and lightweight

  • High accuracy and high stiffness

  • Well equipped with required accessories

  • High stiffness and lightweight structure

  • P/N INFO

SK SERIES

The SK single axis robot is identical to the KK series but incorporates Hiwin's patented SyncMotion™ Technology for quieter and smoother movement, superior lubrication and longer service life.

  • Easy for system design, installation and maintenance

  • Compact and lightweight

  • Quiet and smooth movement

  • High accuracy and high stiffness

  • Well equipped with required accessories

  • High stiffness and lightweight structure

  • P/N INFO

KA SERIES

The KA single axis robot is actuated by a motor-driven ballscrew or belt and is guided by a linear guideway. The base is made from lightweight aluminum. It is suitable for semiconductor and industrial automation applications.

  • Ease of maintenance

  • Low production cost

  • Long strokes

  • High repeatability ± 0.01mm

  • Multiple motor configurations

  • P/N INFO

KS SERIES

The KS single axis robot is actuated by a motor-driven ballscrew or belt equipped with a stainless steel cover strip to prevent particles from entering or exiting. Due to the dust-proof design, this type of single axis robot is ideal for the manufacturing of semiconductor equipment, LED examination equipment, medical and inspection equipment, etc.

  • Dust-proof design

  • Clean room class 1,000

  • Precision and high speed

  • Easy installation

  • P/N INFO

KU SERIES

The KU single axis robot has a lightweight construction that offers high performance in position accuracy and efficiency. This robot contains a motor-driven ballscrew module equipped with a stainless steel cover strip to prevent particles from entering or exiting.

  • Low production cost and compact

  • High performance dust-proof design

  • Easy installation and maintenance

  • P/N INFO

KE SERIES

The KE single axis robot offers a lightweight, compact design that allows for easy system installation and maintenance. This robot contains a motor-driven ballscrew module equipped with a stainless steel cover strip to prevent particles from entering or exiting.

  • Low production cost and compact

  • MG series guideway used

  • Closed dust-proof design

  • Easy installation and maintenance

  • P/N INFO

KM SERIES

Hiwin KM Cartesian robots are designed to be a high quality and cost effective solution for companies to integrate into their OEM systems or in house production systems. The value of these robots is that they save the customer from using their own valuable employee resources to design, source parts, and assemble their own Cartesian robot. The KM Cartesian robots utilize high quality components to maximize quality, reliability, and performance of the system.

​

The KM Cartesian robots are multi-axis robots consisting of KK single axis robots as their core component. They are integrated into a system with mounting brackets, sensors, cable chains, couplings, cables, motors, and drives.

  • Saves on cost of engineering resources

  • Saves on cost of assembly

  • Saves time sourcing multiple components for system

  • Hiwin servo motors and servo drives available

  • Incorporates rigid and low profile KK single axis robots

  • Available in 5 standard platform sizes

  • Common parts across platform sizes

  • System risers available

  • Includes cable management

  • Includes limit and home sensors

  • P/N INFO

LINEAR ACTUATORS

LAM SERIES - LAM1, LAM2, & LAM3

  • Screw types: Ballscrew / ACME

  • Protection: IP54

  • LAM1 series is compatible with LAK2 / LAK2LR / LAK2D / LAK2BN / LAK2J / LAK6B

  • LAM2 & LAM3 series are complatible with all controllers

  • Working temp: +5oC - 40oC

  • Stroke length: 100mm - 200 mm

  • P/N INFO

LAI SERIES - LAI1 & LAI2

  • Screw types: Ballscrew / ACME

  • Protection: IP20

  • LAI1 series is compatible with LAK2 / LAK2LR / LAK2BN / LAK2J / LAK2D / LAK6B

  • LAI2 series is complatible with all controllers

  • Working temp: +5oC - 40oC

  • Stroke length: 200mm - 300 mm

  • P/N INFO

LAS SERIES - LAS1, LAS2, LAS3, LAS4, & LAS5

  • Screw types: ACME

  • Protection: IP54

  • LAS5 series is compatible with LAK2 / LAK2BN / LAK6B

  • LAS1, LAS2, LAS3, & LAS4 series are compatible with all controllers

  • Working temp: +5oC - 40oC

  • Stroke length: 100mm - 200 mm

  • P/N INFO

LAN SERIES - LAN1, LAN3, LAN3A, LAS4, & LAS5

  • Screw types: ACME

  • Protection: IP54

  • LAN3 and LAN3A series are compatible with LAK6B / LAK2J

  • LAN4 series is compatible with LAK2 / LAK2LR / LAK2D / LAK2BN / LAK2J / LAK6B

  • LAN1 & LAN5 series are compatible with all controllers

  • Working temp: +5oC - 40oC

  • Stroke length: 200 mm

  • P/N INFO

LAC SERIES

  • Screw types: ACME

  • Protection: IP54

  • Compatible with all controllers

  • Working temp: +5oC - 40oC

  • Stroke length: 400mm

  • P/N INFO

Anchor 3

Headquartered in Hackettstown, NJ, Rollon Corporation is an International Group that has been designing and manufacturing power transmission products since 1975. The Company has developed many families of products capable of solving a great number of problems in machine design and mechanical fields, or wherever there is the need to move machine parts using simplicity and a low coefficient of friction.



The majority of Rollon products are based on the general principle of a C-shaped rail with internal raceways where, depending on the application, different types of sliders can move. The main advantages of the Rollon components compared to other linear solutions on the market is that they provide products that are designed to be straight forward, compact, efficient, effective, and economical.

COMPACT RAIL

This linear motion guide-rail system is an easy, precision roller bearing solution that allows for rail mis-alignment in both out-of-parallel and out-of-plane conditions. With the large rolling elements used inside the ROLLON Compact sliders, dirt and contamination are less of a problem than with that of recirculating-ball carriages. Since the Compact rail sliders run on an induction heat treated steel surface, they are able to move very fast, very quite, and with an extremely low coefficient of friction. The standard "NTE" style slider has a full body lateral seal, spring energized scrapers, and a felt wick reservoir at each end for complete self-lubrication. The easy preload setting for every Compact Guide-rail slider can be set according to the exact needs of the application so as to maintain stiffness and a low coefficient of friction.

  • Each of the guide-rail series is known by the dimension across the back of the rail mounting surface: 18, 18mm or .71"; 28, 28mm or 1.10"; 43, 43mm or 1.69"; 63, 63mm or 2.43"

  • P/N INFO

CURVILINE

The creativity of design engineering pushes the need for a variety of motions to the limits. Standard rotary or linear motion products do not always provide an answer. That is where the Curvi Line alternative opens a variety of design possibilities. Curvi Line is the only motion solution available that can be made to your specification. This provides you with the ultimate in creativity and flexibility.

  • Radius as small as 120mm (4.72")

  • Maximum rail length 3140mm (123.6")

  • Standard curves of 45° and 90°

  • Constant radius curves

  • Variable and multiple radius rails

  • P/N INFO

  • Zinc-plated rails bent to your specification in low quantities

  • 3 or 4 lubed for life, high precision rollers

  • Specially designed "swivel sliders" provide consistent motion

  • Loads from 400N (90 lbf) to 1130N (254 lbf)

EASYSLIDE

Simplicity is the distinguishing characteristic of the Easy Rail family of steel linear bearings. Designed to quickly and easily fit into demanding applications, these simple yet durable bearings provide engineers with innovative linear solutions designed to solve real world applications.

They are most suitable for applications requiring a combination of compactness, smooth movement, high load capacity, versatility, and affordability. When reliability is key and ease-of-mounting take precedence over absolute precision, Easy Rail is the ideal linear motion system.

The Easyslide family contains five different sized sections: 22mm, 28mm, 35mm, 4mm, and 63mm - all of which offer linear precision of up to 100 microns and load capacities of several thousand pounds per slider. With many different slider lengths available per section, several hundred different combinations of solutions are possible.

X-RAIL

The TEX30 rail is made of 316 stainless steel, its bearings of 440 stainless steel. The bearings are sealed and grease packet for life. The none harden rails make it a breeze to modify or customize them.

The TEX30 offers linear whisper speeds of up to 60"/sec. Its radial ball bearings design allows for minimal friction between rail and bearing with a coefficient of friction of 0.01. Low friction provides excellent running characters even where other bearings bind or "stick".

​

ROLLON's size 30 X-Rail system represents one of the most suitable radial bearings design on the market presently. Yet it offers great load carrying abilities of up to 180lbs. per slider in its upright position. The rail measures a width of 1 1/8" and a height of roughly 4/5" including the slider.

TELESCOPIC RAIL

Telescopic Rail family is divided into the following types of products: Telescopic slides with hardened races; Telescopic slides with non-hardened races; and Semi-telescopic slides with rails that extend more than half of their length out of either side of the fixed part of the slide.

  • Telescopic Rails are made from cold-drawn bearing steel - never from bent sheet metal.

  • They have hardened 60 HRc races to provide the smoothest movement at all times.

  • They work well with shocks and vibrations that render other slides inoperative immediately.

  • They have minimal deflection at the tip of the fully extended slide - even while carrying maximum loads.

  • They can reach strokes of over 2 m (6.5 ft) in one direction and can double that by doing the same out the other side.

  • Telescopic rails are also available in custom extended or reduced stroke

The Light Rail family of products comprises nylon coated steel telescopic slides, ball aluminum or steel telescopic rails.

LIGHT RAIL

Light Rail is best suited to applications where its more important to have lightweight rails than rails that can transfer high capacity loads. The Light Rail family of products offers a complete platform of light telescopic and semi-telescopic rails, all designed to provide maximum versatility.

ECO SYSTEM

Eco System's products have been designed to fit in applications where quality movement is needed at a low price. The patented design offers a well-protected, smooth slide that is easily and quickly mounted.

​

Eco System combines the quality associated with all of ROLLON's products with the affordability needed in application sectors like industrial protective panels, vehicle slides, and machine tool doors.

Eco System is the answer to labor intensive, homemade solutions, cheap bent steel slides, or expensive, overdesigned round or profiled shafting.

​

The products were designed to keep damaging dirt and particles out. The contact between the rollers and the raceways occurs inside the specially shaped profile, protected from accidental impacts and from debris and impurities.

UNILINE SYSTEM

The Uniline System is a belt driven actuator with compact rail bearings. The A75 Uniline offers a 275"/sec. high speed and over 20 ft. long stroke design for a wide range of applications. The A75 offers load capacities of up to 1233lbs. in radial direction a and moments of up to 1849 in-lbs. in Mz direction is prefect for applications where economics play a large factor and long strokes work against most actuators. The high speed performance do not jeopardous noise, 72DBA are very quite for this fast moving system. Its large TLV43 Compact Rail system is constructed of large radial bearings that operate on a hardened steel surface and have the ability to operate in contaminated environments. The rail is placed flat against the inside bottom of the extrusion to minimize the overall dimension 2.9" x 2.9".

Anchor 1

Bishop-Wisecarver invented the DualVee guide wheel and has been a world leader in guide wheel technology since 1970. DMT integrates three main components, the DualVee guide wheel, its DualVee mating track with patented mounting shoulder, and the DualVee support bushing. Their product line includes components, linear guides, linear systems, rotary guides and systems, and aluminum machine framing. Stainless steel, high temperature, and clean room compatible products are among Bishop-Wisecarver's more recent product introductions.  New product development continues to be an ongoing process at the Bishop-Wisecarver Corporation, with innovative designs being introduced at regular intervals.

DUALVEE - LINEAR VEE GROOVE GUIDE WHEELS

DualVee provides users four different v guide wheel options: Original V Bearing Guide Wheels, Studded V Bearing Guide Wheels, patented Integral V Bearing Guide Wheels, and NEW patented Washdown Wheels . Wheels then run on either Single Edge Track or Double Edge Track. Wheels are mounted using Journals and Bushings. Functionality and life of your DualVee system can be increased by incorporating any of our accessory items: Wheel Covers, Lubricators, Track Plate Assemblies, and Wheel Plate Assemblies.

HEPCOMOTION GV3 - LINEAR GUIDANCE & TRANSMISSION

​GV3 provides a wide array of precision linear guide components utilizing guide wheel and roller wheel technology. Slides are available in three different precision grades, ranging from completely ground surfaces to as-drawn quality, to fit performance and economic needs. Lubed-for-life guide wheels come in twin bearings, double row bearings, and compact slimline bearings. GV3 may be used as a simple guide or as a self-actuated rack or belt driven system.  To view a list of compatible slide/bearing combinations, see the GV3 mix and match chart.

MADEWELL - RADIAL WHEELS & CROWN ROLLERS

Part of the new DualVee family of integral wheels, MadeWell crown rollers are available in steel (sizes 1, 2 and 3) or overmolded high performance polymer (sizes 0, 1 and 2).  Like patent pending DualVee integral guide wheels, MadeWell crown rollers offer a one piece construction. The inner raceway is actually the stud (except on the smallest sizes).

HEPCOMOTION HDS2 - HEAVY DUTY SLIDE

The HDS2 Heavy Duty Slide System line adds assembled carriages, two new sizes of construction beam, and a host of improved features to the proven HDS product line.  Three new larger bearing sizes up to 150mm provide even higher load capacity (up to 50kN each).  The expanded line also includes a new larger size 33 single edge V slide and flat tracks, as well as stainless steel or corrosion resistant component options.  The advanced HDS2 system provides the flexibility for many sizes and types of heavy duty components to be interchanged to achieve a comprehensive combination of space and performance possibilies.

HEPCOMOTION PRT2 - PRECISION RING & TRACK

Not all motion needs are linear, which is where PRT (Precision Ring and Track), DTS, and commercial product lines come in. The PRT line offers rotary systems, while the DTS line offers actuated rotary systems. For customers seeking a more economical rotary system not requiring high accuracy, the commercial series offers a great alternative.

HEPCOMOTION HDRT - HEAVY DUTY RING & TRACK

HDRT combines the flexibility and function of the PRT Ring Slide and Track system with the size and strength of the HDS product line to support loads of up to 40kN (8,992 pounds).

HEPCOMOTION DTS - DRIVEN TRACK SYSTEM

DTS utilizes oval and rectangular track systems and provides actuation by means of a high tensile strength timing belt. Motion may either be continuous or intermittent to fit customer needs. Carriages are often fixed to the timing belt at equal pitch lengths, and in the event that a carriage’s path is impeded, it will disengage from the drive. DTS may also be mounted to high strength aluminum beams. These DTS positioning table systems are fully compatible with extrusion framing. Other accessories and options include AC geared motors, IEC frame gearboxes, pulley bearing units, trip latches, and sensor mounting brackets.

Anchor 4

EDrive actuators are designed, manufactured, tested, and serviced in West Hartford, CT.  Founded in 1980, EDrive Design, Inc. initially developed a wide variety of heavy duty ball screw linear actuators, targeting the machine tool retrofit market. Thus, we established our guiding principles of conservative design, rugged construction, long life, and high precision.

​

EDrive manufactures electro-mechanical linear servo actuators that replace hydraulic cylinders for motion control applications.

EDrive has shown consistent success in the toughest applications, e.g. high loads, high speeds, high precision, and extreme durability. Precision ball screw systems, tailored for maximum life, load and speed, provide the motion while fully enclosed, thus eliminating contamination related failures.

​

A "standardized" product line facilitates ready availability; however, modified designs in the interest of easing the customers' utilization of our products is done willingly. EDrive is focused on understanding the application, recommending the optimum solution, and making it easier for the customer to mechanically and electrically interface with their existing equipment.

EDrive continues to expand the capabilities of its products; with the most recent addition of the HDL™ offering an internal load cell for precise control of force as well as position and motion.

​

After market service also remains a high priority. Emergency repairs are routinely performed within one day.  If the required ballscrew is not in stock, a typical rebuild is 4-5 days.

E-TAC ET

  • Velocity to 33 in/sec

  • Sealed Chamber Design with Purge Provisions

  • Adjustable Limit Switch Positions

  • Accepts Any Motor up to 3" Square

  • P/N INFO

VECTAC VT

  • Force From 400 to 2,000 lbs

  • Strokes to 30 inches maximum

  • Velocity to 40 in/sec

  • Sealed Chamber Design with Purge Provisions

  • Adjustable Limit Switch Positions

  • Accepts Any Motor

  • P/N INFO

L-TAC LS

  • Force From 400 to 2,000 lbs

  • Strokes to 48 inches maximum

  • Velocity to 40 in/sec

  • Sealed Chamber Design with Purge Provisions

  • Adjustable Limit Switch Positions

  • Accepts Any Motor

  • P/N INFO

ELIMINATOR HD

  • 2,000-25,000 lbs Force

  • Heavy Wall Steel Construction

  • Longest Life

  • Simultaneous High Thrust with High Speed

  • Piston with Rugged Anti Rotation Feature

  • P/N INFO

ELIMINATOR HDL with Integral Load Cell Option

  • Integrated force measurement

  • 2,000-25,000 lbs Force

  • Accurate within ½ percent of rated force

  • Conforms to latest standard ASTM E4 for

  • Testing Machines

  • Internal load cell – wire connections are "out of the way"

  • Load cell rated for 100 million cycles

  • P/N INFO

ELIMINATOR HDR with Roller Screw Option

  • 4,000-25,000 lbs Force

  • Heavy Wall Steel Construction

  • Longest Life

  • Simultaneous High Thrust with High Speed

  • P/N INFO

ELIMINATOR SD

  • 30,000-66,000 lbs Force

  • Heavy Wall Steel Construction

  • Highest (B10) Life Rating

  • Piston with Rugged Anti Rotation Feature

  • Adjustable Limit Switch Positions

  • P/N INFO

MT PRECISION

  • Machine Tool Grade

  • High Precision with Force to 15,000 lbs

  • Rugged Steel Construction

  • Designed for High System Stiffness

  • P/N INFO

EA SERIES

  • Part of the Legacy Product Line

  • Modified or Custom Built

  • High Precision with Force to 15,000 lbs

  • Rugged Steel Construction

  • Designed for High System Stiffness

  • P/N INFO

SLIDES

  • Part of the Legacy Product Line

  • Single & Multi-Axes

  • Rugged Ductile Iron Slide

  • Hardened and Ground Steel Ways

  • P/N INFO

LIMIT SWITCHES

  • Part of the Legacy Product Line

  • Linear & Rotary

  • Hermetically Sealed to IP67 Standards

  • P/N INFO

Anchor 5

Schneeberger is a global supplier of linear bearings and systems based in Roggwil, Switzerland with additional manufacturing plants in Germany and Czech Republic.



Schneeberger Linear Technology: "Essentials for the Best!"  The name Schneeberger has been synonymous with modern linear guide technology. The modern and demanding user of linear technology has confidence in the capabilities and products of Schneeberger. Throughout the world, important manufacturers of machine tools, high-tech plants and medical equipment rely on roller-, ball- and needle guideways, MONORAIL systems and positioning units from Schneeberger.

LINEAR GUIDEWAYS / BEARINGS

  • ​Frictionless roller guideways move machinery or assemblies in linear directions

  • Type RN, RNG (with rollers)

  • Type R (with balls or rollers)

  • Type RD (with balls or rollers)

  • Type NO (with rollers or needles)

  • Type MV (with needles)

  • Sizes: 1-12

  • Type NO sizes: 62015, 92025, 2025, 2535, 3045, 3555

  • Type MV sizes: 3015, 4020, 5025, 6035, 7040, 8050

  • Lengths: 20-2000mm

  • P/N INFO

MONORAIL MR

Roller guideway for the machine tool industry

​

High rigidity, great dynamic and static load carrying capacity, outstanding running smoothness and the total enclosure of the carriage are the main features of the MONORAIL guideway. These properties result in higher machining rates while enhancing geometrical accuracy and surface quality of the machined workpieces. Our highly rigid MONORAIL provides improved vibration behavior, smaller vibration amplitudes and thus extends tool life.

MONORAIL BM

BM ball guideways are reliable components for the entire range of industrial applications

​

SCHNEEBERGER's MONORAIL BM linear ball guides features excellent dynamic properties and many commercial benefits. Designed with a small number of cleverly arranged components, it provides for excellent running properties due to the small number of transitions in the ball tracks, which lead to very quiet running, low pulsation and low friction as well as high travel speeds. The use of a trapezoidal rail section results in an extremely rigid guideway coupled with a substantial reduction in servicing time as additional wipers can be changed without dismantling the carriage. Complete sealing of the carriage guarantees maximum reliability coupled with a long service life. This robust and economical guideway rounds off SCHNEEBERGER's range of products for industrial applications with high demands on speed, reliability and consistant running properties.

MONORAIL BM WR / BM SR

Ball guideway in corrosion-resistant steel for the food industry, clean room applications and more

​

They were developed specially for specifications which would exceed the requirements of ordinary coatings for linear guideways. This is the case when the performance of the product is impaired by corrosion during processes. In applications such as machines for foodstuffs, medical technology and cleanrooms, or vacuum applications, MONORAIL BM WR/SR products ensure that the operation of linear axes is clean, accurate, long-term and free of problems. Furthermore, the MONORAIL WR/SR has the same tried and tested properties of the MONORAIL BM, such as the most effective operating characteristics, high travel speeds and a long operating life.

MONORAIL BZ

Schneeberger offers linear guideway systems - profiled linear guideways with integrated rack and pinion drive

​

Schneeberger's MONORAIL BZ systems are high-precision linear guide systems with integral rack drive, based on the company's proven MONORAIL BM profile guideways with balls. The design of the MONORAIL BZ provides for superb operating characteristics, high load-bearing capacity and rigidity together with a long service life thanks to the use of the tried-and-tested MONORAIL BM profile guideway and to the high transmittable forces, smooth running and optimum positioning accuracy offered by ground, hardened and precise helical gearing of superlative quality.

MINIRAIL / MINI-X

Miniature guideways are compact and precise for maximum productivity

They are extremely robust. Their smooth running precision and reliability are demonstrated in every application. The design, material selection and surface finish of the recirculation element and ball entry zone, guarantee low pulsation and therefore a smooth ride. The range includes eight rail widths which can be combined with up to four carriage sizes.

  • SHORT CARRIAGE VERSION AVAILABLE

  • LONG-TERM LUBRICATION LUBE S AVAILABLE​

  • P/N INFO

Anchor 6
Anchor 7

Nadella is a designer and wolrdwide manufacturer of products including linear guide systems, linear actuators, adjusting nuts and angle gear boxes. Design and production of linear guide systems are not only oriented to standard products, but also to custom solutions for specific customer applications.

Nadella is a designer and wolrdwide manufacturer of products including linear guide systems, linear actuators, adjusting nuts and angle gear boxes. Design and production of linear guide systems are not only oriented to standard products, but also to custom solutions for specific customer applications.

LINEAR GUIDE SYSTEMS

LINEAR GUIDE SYSTEMS

LINEAR GUIDE SYSTEMS

Nadella is specialised in the design and production of linear guide rail and rollers, divided into heavy and light load families, suitable for all applications where high speed and low noise are required and the operating environment is very aggressive. Our rails can be supplied with a single length of 6 meters, can be cut and drilled according to the customers’ needs and can be jointed together.

Nadella is specialised in the design and production of linear guide rail and rollers, divided into heavy and light load families, suitable for all applications where high speed and low noise are required and the operating environment is very aggressive. Our rails can be supplied with a single length of 6 meters, can be cut and drilled according to the customers’ needs and can be jointed together.

Nadella is specialised in the design and production of linear guide rail and rollers, divided into heavy and light load families, suitable for all applications where high speed and low noise are required and the operating environment is very aggressive. Our rails can be supplied with a single length of 6 meters, can be cut and drilled according to the customers’ needs and can be jointed together.

Anchor 8

Nexen is the leading source of linear motion control products, with a highly trained service department. We are dedicated to customer and technical support. Please submit your contact information and we will get back to you. We are headquartered in Vadnais Heights, MN, with our manufacturing facility located in Webster, WI.

PRECISION LINEAR MOTION

Nexen’s Precision Linear Motion technology is a combination of very high precision linear drive systems, compact harmonic gearheads, and high force brakes located at the drive motor or the linear guide system. Nexen provides zero backlash from the servo motor all the way through the linear drive system.

​PRODUCTS AVAILABLE

  • Rail Brakes

  • Roller Pinion System

  • Rod Locks

  • Servo Motor Brakes

  • Ball Screw Brakes

  • Linear Couplings

  • Linear Motion Accessories

  • P/N INFO

PRESION ROTARY MOTION

Nexen’s Precision Rotary Motion technology is a combination of very high precision rotary drive systems, compact harmonic gearheads, high torque rotary brakes, and mechanical torque limiters all delivering zero backlash.

​PRODUCTS AVAILABLE

  • Precision Ring Drive Systems

  • Roller Pinion Gear System

  • Ball Screw Brakes

  • Servo Motor Brakes

  • Indexer Brakes

  • Harmonic Gearheads

  • Mechanical Torque Limiters

  • Rotary Motion Accessories

  • P/N INFO

POWER TRANSMISSION

Power transmission requires torque and Nexen products provide torque in a wide variety of clutches, brakes, torque limiters and coupling products. Nexen air actuated products are more efficient and economical than electrically actuated products of the same size. Air, unlike electricity, does not generate heat during engagement. Less heat allows greater torque transmission and efficiency. Nexen’s simple designs are easy to use and maintain. When properly applied these products have a long service life making the cost of ownership much less than competitive products.

​PRODUCTS AVAILABLE

  • Friction Clutches (Single Plate)

  • Tooth Clutches

  • Multiple Disc Clutches

  • Dual Plate Clutches

  • Torque Limiters

  • Friction Brakes

  • Clutch-Brake Combinations

  • ​

  • P/N INFO

TENSION CONTROL SYSTEMS

Web control systems include tension control and web guide systems for the web industry.

​PRODUCTS AVAILABLE

  • Tension Control Clutches and Brakes

  • Sensors

  • Tension Controllers

  • Tension Meters and Amplifiers

  • Auxiliary Controls

  • Web Guide Systems

  • Tension Control Accessories

  • P/N INFO

Anchor 9

Exlar Electric Actuators from Curtiss-Wright deliver an unmatched range of capabilities, power, and performance in both linear and rotary configurations. Select from a broad range of products to find the most robust, reliable, and cost-effective solution for nearly any motion application. Exlar actuators offer many distinct benefits over hydraulic, pneumatic, and other electromechanical systems: lower cost to operate, more compact packaging, improved load ratings, increased speed, and longer life.

TRITEX II™ AC ROTARY ACTUATOR

The Tritex II AC rotary actuator sets a new benchmark for high performance and small size. These rotary actuators fully integrate an AC powered servo drive, digital position controller, and brushless motor in a compact, sealed package. By combining the latest electronic power technology with advanced thermal management modeling, these rotary actuators are programmable, powerful and precise. They offer a superior solution for applications that can benefit from a compact and fully integrated device.

  • Fully Integrated Drive/Motor

  • Output torque up to 4,696 lbf-in (530 Nm)

  • Speeds up to 4000 rpm

  • Voltage ratings from 100 - 240 VRMS

  • Eliminates costly, high-maintenance servo cables

  • Optional internal gear reducer

  • P/N INFO

TRITEX II™ AC LINEAR ACTUATOR

By combining the latest electronic power technology with advanced thermal management modeling technology, Exlar has set a new benchmark for performance and size. Tritex II Series actuators integrate an AC powered servo drive, digital position controller, brushless motor and linear actuator in a compact, sealed package. Now you can precisely control motion and solve all of your application requirements with a single, fully integrated device. Simply connect AC power, I/O and communications; and it’s ready to go!

  • Fully Integrated Drive/Motor/Actuator

  • Continuous force up to 3,225 lbf (14 kN)

  • Speeds up to 33 in/s (800 mm/s)

  • Strokes from 3 to 18 in (75 to 450 mm)

  • Voltage ratings from 100 - 240 VRMS

  • Complete stand-alone solution

TRITEX II™ DC ROTARY ACTUATOR

The Tritex II DC powered rotary actuator houses a servo drive, digital positioner and servo motor in a single, compact package. These advanced actuators offer the highest power density and smallest footprint servo driven devices on the market. Their small size and innovative design make it easy to incorporate a fully electronic solution in the space of your existing hydraulic or pneumatic cylinder. Now you can precisely control motion and solve your application requirements with a single, fully integrated device.

  • Fully Integrated Drive/Motor

  • Output torque up to 2078 lbf-in (235 Nm)

  • Speeds up to 5000 rpm per gear ratio

  • Gear ratios up to 100:1

  • Voltage ratings from 12 to 48 VDC

  • Complete stand-alone solution

TRITEX II™ DC LINEAR ACTUATOR

The Tritex II DC powered unit houses a servo drive, digital positioner and electric actuator all in one convenient package. These advanced actuators offer the highest power density and smallest footprint servo drive devices on the market. Their small size and innovative design make it easy to incorporate a fully electronic solution in the space of your existing hydraulic or pneumatic cylinder. Tritex II Series actuators integrate a DC powered servo drive, digital position controller, brushless motorand linear actuator in a compact, sealed package.

  • Fully Integrated Drive/Motor/Actuator

  • Continuous force up to 872 lbf (3879 N)

  • Speeds up to 33.3 in/s (846 mm/s)

  • Strokes from 3 to 18 in (75 to 450 mm)

  • Voltage ratings from 100 to 240 VRMS

  • Complete stand-alone solution

  • P/N INFO

GSX SERIES INTEGRATED MOTOR ACTUATOR

GSX Series integrated motor actuators integrate all the advantages of Exlar® roller screw and T-LAM stator technologies to create powerful and robust solutions with long life. The specially designed roller screw mechanism efficiently converts electric motor power into linear motion. Planetary rollers, assembled around the extending rod, follow threads that are precisely machined on the inside of the actuator’s hollow rotor.

  • Integrated Motor Actuator

  • Continuous force up to 11,528 lbf (51 kN)

  • Speeds up to 37.5 in/s (952 mm/s)

  • Strokes from 3 to 18 in (75 to 450 mm)

  • Voltage ratings from 115 - 460 VRMS and 24 - 48 VDC

  • Compact size

  • Class 1, Division 2 options available

GSM SERIES ELECTRIC LINEAR ACTUATOR

GSM Series electric linear actuators are a superior and cost effective alternative to traditional electric, hydraulic and ball screw systems. The compact design is the culmination of advanced roller screw technology and an integral brushless servo motor. This robust electric linear actuator is ideal for a variety of medium- to high-performance applications. With GSM actuators, everything from food and beverage packaging, to multi-axis turning centers, to aircraft assembly can be done cleaner, faster, and more accurately and efficiently.

  • Electric Linear Actuator

  • Continuous force up to 3,457 lbf (15 kN)

  • Speeds up to 37.5 in/s (952 mm/s)

  • Strokes from 3 to 18 in (75 to 450 mm)

  • Voltage ratings from 115 - 460 VRMS and 24 - 48 VDC

  • Compact size

  • Class 1, Division 2 options available

K SERIES ELECTRIC LINEAR ACTUATOR

The K Series actuators from Exlar provide a truly universal solution for a multitude of rod-style actuator applications. Now available in 60, 75, and 90 mm frame sizes. Two grades of planetary roller screws give you flexibility to select the configuration that is best suited for your application and budget.

  • Electric Linear Actuator

  • Maximum force up to 3,500 lbf (15 kN)

  • Speeds up to 32.8 in/s (833 mm/s)

  • Strokes from 0.7 to 48 in (20 to 1219 mm)

  • Universal solution for rod-style actuation

  • Multiple models and sizes with advanced roller screw

FT SERIES ELECTRIC LINEAR ACTUATOR

The FT Series actuators from Exlar® use a planetary roller screw mounted inside an extruded aluminum housing. These electric linear actuators are compatible with a wide range of standard motors. Motor mounting and gearing configurations are available to meet the requirements of a wide variety of applications. The standard product is offered in four frame sizes with standard stroke lengths up to 48 inches (1219 mm) and a load rating up to 40,000 lbf (177 kN).

  • Electric Linear Actuator

  • Maximum force up to 40,000 lbf (177 kN)

  • Speeds up to 59.3 in/s (1500 mm/s)

  • Standard stroke lengths up to 48 in (1219 mm)

  • Sealed housing options for severe environments

  • Multiple

EL SERIES EXPLOSION PROOF ACTUATORS

The EL Series of explosion proof actuators is deal for valve control, as well as many other applications in hazardous environments. These all-electric actuators easily outperform hydraulics and other competing technologies. Inside the rugged housing is a highly efficient planetary roller screw integrated with a high torque servomotor. For reliable and precise operation, as well as the ability to handle heavy loads over thousands of hours, these actuators consistently deliver measurable results—even in harsh, arduous conditions.

  • Explosion Proof Actuator

  • Continuous force up to 4,081 lbf (18 kN)

  • Speeds up to 37.5 in/s (953 mm/s)

  • Strokes from 4 to 18 in (100 to 450 mm)

  • Up to 90% efficiency and 100% duty cycle

  • Engineered for high performance and long life

  • Multiple models and sizes with advanced roller screw technology

  • P/N INFO

bottom of page
