RTA, the second largest stepping drive manufacturer in Europe, offers a wide range of Bipolar Chopping Drives in both AC and DC ranges. RTA also has Indexing Programmable Stepper controllers for Daisy Chaining and MultiAxis Applications. The newly introduced X-Mind Series Driver has been in use in many countries including the US working on very critical applications primarily in the packaging/printing and Labeling industries.
RTA is a leading European manufacturer of bipolar chopper stepper motor drives for two phase hybrid 200 step/rev motors. Drives range from 0.75 Amp @ 24V upto 14 Amps @ 240V and are available in several mounting versions such as Eurorack (illustrated), OEM and panel mounting. The drives are available in resolutions from the standard 200 step/rev (full) to 400 step/rev (half), 800 step/rev (quarter) and 4000 (ministep). They are designed for high reliability motion control in industrial environments and are backed by over 20 years experience in stepper motor drive design.
The drives are easily controlled by step and direction inputs from a computer or programmable logic controller. Applications include laboratory instrumentation, back stop positioning, CNC retrofitting, labelling machines, packaging machines, XY tables, pick & place and testing machines.
Our E.M.C statement applies to the installation of these products. At the time of web site publication, all RTA drives except the BCW02 and SD stepper motors claim European CE and Australian C-tick conformity. The CE compliance is important for machine manufacturers seeking clients in European countries.
PACKAGED DRIVES
CSD 90 SERIES - CSD 92 & CSD 94
Very Low cost for small motors
Packaged version of the CSD drives
DC power supply
24 - 45 V supply and motor output
400/800/1600/3200 step/rev resolution
Suitable for 17, 23 and 34 frame stepper motors
Small mounting area
0.7 - 4.4 Amp output

NDC 90 Series - NDC 94 & NDC 96
Low cost
Packages version of the NDC drives
DC power supply
24 - 75 V supply and motor output
0.65 - 6 Amp output
400/500/800/1000/1600/2000/3200/4000 step/rev
Suitable for 17, 23 and 34 frame stepper motors
Built in ramped oscillator
Small mounting area
Opto isolated inputs

PLUS A SERIES - PLUS A3 & PLUS A4
DC unregulated supply
35 - 85 VDC power supply (A3)
70 - 140 VDC power supply (A4)
1.9 - 8 Amp output
400/500/800/1000/1600/2000/3200/4000 step/rev resolution
Small mounting area
Opto isolated inputs
Suitable for 23 and 34 frame stepper motors

PLUS B SERIES - PLUS B3 & PLUS B4
AC Supply from mains transformer
25 - 62 VAC power supply (B3)
50 - 100 VAC power supply (B4)
1.9 - 8 Amp output
400/500/800/1000/1600/2000/3200/4000 step/rev
Small mounting area
Opto isolated inputs
Suitable for 23 and 34 frame stepper motors

PLUS K SERIES - PLUS K4 & PLUS K5
With Built in indexer
AC supply from mains transformer
35 - 85 VDC power supply (K3)
70 - 140 VDC power supply (K4)
1.9 - 8 Amp output
400/500/800/1000/1600/2000/3200/4000 step/rev resolution
Stores upto 16 motion programs
Stand alone operation, no PLC needed
Datum search instructrion
Opto isolated inputs

PLUS K SERIES - PLUS K4 & PLUS K5
With Built in indexer
AC supply from mains transformer
35 - 85 VDC power supply (K3)
70 - 140 VDC power supply (K4)
1.9 - 8 Amp output
400/500/800/1000/1600/2000/3200/4000 step/rev resolution
Stores upto 16 motion programs
Stand alone operation, no PLC needed
Datum search instructrion
Opto isolated inputs

PLUS E SERIES - PLUS E3 & PLUS E4
Encoder feedback for missing steps
AC supply from transformer
25 - 62 VAC power supply
2.4 - 8 Amp output
Suitable for 23 and 34 frame stepper motors
400/500/800/1000/1600/2000/3200/4000 step/rev resolution
Small mounting area
Alarm output for synchronisation loss
Encoder mounted on back of motor
Opto isolated inputs

X-MIND B SERIES - X-MIND B4 & X-MIND B6
AC mains power supply (110 to 230 VAC)
No need for mains transformer
Ideal for high voltage, high speed applications
Designed for high inductance motors
400/500/800/1000/1600/2000/3200/4000 step/rev resolution
3.4 - 6 Amp Output
Suitable for selected 34 and 42 frame motors
Opto isolated inputs
155 - 325 V motor output

X-MIND K SERIES - X-MIND K4 & X-MIND K6
With Built in indexer
400/500/800/1000/1600/2000/3200/4000 step/rev
AC mains power supply (110 to 230 VAC)
Stores upto 16 motion programs
Stand alone operation, no PLC needed
2.0 - 25Nm motor torque range
155 - 325 V motor output
4.5 - 12 Amp Output
Suitable for 34 and 42 frame motors
Opto isolated inputs

BCW 02
High Voltage, high current
